Fontan Mobilstar

The Fontan Mobilstar is a Vehicle moutable ULV aerosil applicator.

The Fontan Mobilstar is equipped with:

• a 16-18 hp four-stroke engine with electrical starter (also fitted with a manual backup starter)
• a fuel tank with a capacity of 20 l and level indicator
• a dry running side channel compressor
• Two universally adjustable spraying heads
• A control panel/remote control for operatin gall function sof the applicator
• A flushing tank for automatic cleaning of the feed lines and spraying heads.



There are a number of models:

Model M

• Flow rate setting (liter per hour)
• Interchangeable dosage nozzles with specific flow rates
• Delivery of the spraying liquid is achieved by a positive pressure in the spraying tank



Model E

• Flow rate is entered, via buttons, on the control panel/remote control and shown on the display
• Delivery of the spraying liquid is achieved by a chemical resistant stainless steel gear pump which draws the spraying liquid from the spraying tank.  The output qualntity can be calibrated electronically



Model EK

• This comes with a 12.5 m extension flexi-hose fitted with a single rear entry spray head.
• Applications can be carried out externally through positioning the spray head inside air vents or windows etc... A tripod also comes as standard to offer greater accessibility for many applications.
• Disinfection can be carried out using this system as the machine internals are suitable to withstand aggressive compounds used.



Accessories

Optional Accessories for all models include a heavy duty dry batter, 12 V, 36Ah.

Model E and ER have the option of spraying taks equipped with level indicator, big filling opening vents, drainage aperture, mounting and quick release coupling to connect the chemical line - stainless steel (69 l) and Polypropelene (80l, 150l 300l and 500l).

Model M has additional dozage nozzles on special request and an hour meter.



General areas of use are -

• Warehouse,
• Agriculture (Grain Store, Potato Stores with K Kit),
• Factory,
• Greenhouse,
• Sewer System,
• Waste Recycling Centre,
• Extensions and Roof Spaces



Technical Features -

Motor	Optional 16 HP or 18 HP
Cubic Capacity	480 cm³ (16 HP) | 570 cm³ (18 HP)
Power	11760 W (16 HP) | 13240 kW (18 HP)
Speed	3000 RPM
Starter	Electric (Additional Manual Recoil Starter)
Battery	12 V/36 Ah Dry Cell Battery (Optional)
Petrol Tank	20 Ltr with Suction Set and Level Indicator
Petrol Consumption	4 Ltr/h
Rinsing Tank	5 Ltr Polyethylene
ULV Mode Output	5 Ltr/h - 50 Ltr/h (Droplet Size < 30 μm)
ULV - Plus Mode Output	51 Ltr/h - 100 Ltr/h (Droplet Size < 40 μm)
LV Mode Output	5 Ltr/h - 100 Ltr/h (Droplet Size 75 - 100 μm)
Dimensions	87 x 75 x 95 cm (Without Chemical Tank)
Weight (Empty)	135 kg (Mobilstar M inc 69 Ltr Chemical Tank) 127 kg (Mobilstar E without Chemical Tank) 127 kg (Mobilstar ER without Chemical Tank) 139 kg (Mobilstar EK without Chemical Tank)
